FUNCTION DISPLAY
Compact design, user-friendly
Automatic Bin Lifter
Bin capacity: 2 cubic meters
Automatic lifting, time and labor saving
PRODUCT VIDEO
Technical Paramenters
Max Speed (Full Load)km/h71
| Project | Unit | Parameter |
|---|---|---|
| Product Brand | / | Baiyi |
| Vehicle Model | / | JBY5020ZZZBEV |
| Gross Vehicle Weight (GVW) | T | 1.95T |
| Dimensions (L×W×H) | mm | 4050×1280×1980 |
| Cargo Box Dimensions (L×W×H) | mm | 2375×1200×1170 |
| Total Mass | kg | 1950 |
| Curb Weight | kg | 995 |
| Rated Payload | kg | 890 |
| Wheelbase | mm | 2355 |
| Voltage/Capacity/Power | / | 307.2V/52Ah/15.97kWh |
| Driving Range | km | 135 |
| Charging Time (SOC: 20%-80%) | h | 6-8h AC Slow Charge/1h DC Fast Charge |
| Operating Time per Charge | h | 4-6 |
| Max Gradeability | % | 20 |
| Braking Distance (Full Load at 30km/h) | m | 5 |
| Min Turning Diameter | m | 9.8 |
Click the download button,you can get all machine parameters
High-Performance Chassis
Built on a 1.95-ton light-duty, heavy-load sanitation Class II chassis, featuring front MacPherson independent suspension and rear non-independent leaf spring suspension. The upper structure adopts an intelligent control system with a high degree of automation, strong reliability, low failure rate, and user-friendly operation. The vehicle is equipped with a high-voltage system supporting both DC fast charging and AC slow charging. Additional features include electronic power steering, hydraulic braking, front disc/rear drum brakes, air conditioning (cooling and heating), standard ABS, and reversing radar. It also comes with EPS steering assist and an EBS brake vacuum assist system, ensuring flexible steering and reliable braking.
Container
The bottom of the container is made of stainless steel, with an overall electrophoretic paint finish. It is corrosion-resistant, rust-proof, and has excellent sealing properties, making it leak-proof and suitable for self-loading and unloading.
Control Screen
– High-definition LCD dashboard for convenient operation
– Spacious driver’s cabin
– Smooth, stable, and quick driving
VEHICLE ADVANTAGES
Convenient Charging
The vehicle uses a Chinese national standard DC charging port, with the interface conveniently located on the side of the body for easy operation. This design is compatible with most mainstream charging piles on the market, facilitating rapid energy replenishment for the vehicle. It effectively reduces charging time and ensures the vehicle’s continuous operational capability, serving as a crucial guarantee for the efficient performance of a pure electric sanitation truck.
Cabin
The seat is adjustable forward and backward and equipped with a three-point safety belt. In addition to standard functions, the dashboard features a national-standard GPS positioning terminal and other onboard devices, along with a vehicle self-diagnostic system and a reserved OBD communication interface. The cab is equipped with dual-function air conditioning (cooling and heating) to ensure a comfortable working environment. *Optional: onboard reversing camera for improved visibility during operation.
Efficient Lighting
The vehicle is equipped with LED headlights, which provide bright and focused illumination, significantly improving driving safety in low-visibility and nighttime conditions. LED technology also offers the advantages of low energy consumption and a long lifespan, reducing maintenance costs and complementing the vehicle’s modern design.
