FUNCTION DISPLAY
Flexibility
Small Turning Radius
Equipped With A Sprinkler System
Cleaning width 1900mm
PRODUCT VIDEO
Technical Paramenters
| NO. | Item | Unit | BY-S11 |
|---|---|---|---|
| 1 | Work efficiency | ㎡/h | >7500 |
| 2 | Battery | V/ah | 48/61 |
| 3 | Main brush motor power | w | 800 |
| 4 | Edge brush motor power | w | 100 |
| 5 | Fan motor power | w | 360 |
| 6 | Drive motor power | w | 1000 |
| 7 | Garbage bin capacity | L | 80 |
| 8 | Water tank capacity | L | 50 |
| 9 | Cleaning width | mm | 1200 |
| 10 | Main brush width | mm | 490 |
| 11 | Driving speed | Km/h | ≤8 |
| 12 | Turning radius | mm | 1300 |
| 13 | Anti trolley control | / | Brake |
| 14 | Vehicle usage time | h | 3-4 |
| 15 | Max Climb Capability | % | 15 |
| 16 | Noise | Db | ≤70 |
| 17 | Charging time | h | 8-10 |
| 18 | Curb weight | kg | 380 |
| 19 | Dust shaking method | / | Hand cranked dust |
| 20 | Dimensions(Lx W x H) | mm | 1600*1545*1200 |
Click the download button,you can get all machine parameters
Chassis Section
The entire vehicle frame structure adopts an electrophoretic coating process, providing double protection against wind and rain corrosion. The vehicle is compact, aesthetically pleasing, easy to operate, and highly adaptable. Compared to manual sweeping, it is more time-saving and labor-saving.
User-Friendly Design
Features like the master switch control, small turning radius, and easy-to-empty dust box make it very user-friendly.
Convenient Dust Box
The wheeled dust box is easy to empty.
VEHICLE ADVANTAGES
Travel Drive Motor
Uses a well-known domestic brand AC asynchronous motor with stable performance and a motor power of 2500W
Airport-Specific Solid Tires
Sturdy and Durable, High Load Capacity, Wear-Resistant, and Long-Lasting
Effective Dust Reduction
Efficient atomizing nozzles and built-in powerful dust control system reduce dust emissions effectively.
